Electron Probe Micro Analysis Laboratory

Electron Probe Micro Analysis Laboratory located at Headquarters, Hyderabad is equipped with Cameca (France) make SX-100 system. The Electron Probe Micro Analyser (EPMA) system equipped with versatile electron gun compatible with W filament and LaB6, three vertical and one inclined Wavelength Dispersive Spectrometers (WDS), one Energy Dispersive Spectrometer (EDS) and built-in microscopy tools, allows simultaneous X-ray, SEM and BSE imaging and sophisticated visible light optics. It provides a very flexible sample inspection mechanism with wide range of image magnification. The excitation beam regulation system and automated sample stage movements provide outstanding stability and measurement repeatability.

Micro-domain near-surface qualitative and quantitative chemical analysis from Na to U with a general detection limit of 100 ppm is undertaken in the laboratory. Detailed morphological, textural and compositional (qualitative) data are obtained through SE, BSE, X-ray images and spectral scans.


Electron Probe Micro Analysis Laboratory

Electron Probe Micro Analysis Laboratory, Hqrs, Hyderabad
Electron Probe Micro Analysis Laboratory

BSE image of uraninite in quartz biotite schist, Jaduguda, Singbhum Shear Zone, Jharkhand
